AVK SUPA LOCK™ TAPPING SADDLE WITH BLADE SHUT-OFF, PN16

For under pressure tapping on PE/PVC pipes

AVK headquater in Skovby Galten, Denmark

Contact

AVK International A/S

Bizonvej 1, Skovby, 8464 Galten, Denmark

Supa Lock™ tapping saddle with blade shut-off for under pressure tapping on PE/PVC pipes. For drinking water and neutral liquids to max. 70° C

AVK Supa Lock™ is a patented service connection system consisting of tapping saddles, valves and fittings with a fast two-step assembly without threads or use of tools. Supa Lock™ features a corrosion protected push-in and quick-lock joint secured by a safety retainer which prevents demounting under pressure. The tapping saddles are designed with Supa Lock™ socket outlet, and features a cassette for blade shut-off acting as a temporary valve during the drilling process.

Variant 100/30-003
Connection: Supa Lock™
Material: Ductile Iron
DN: DN80 - DN200

Features

  • Tapping saddle of ductile iron with fusion bonded epoxy coating in compliance with DIN 3476 part 1 and EN 14901, GSK approved
  • Supa Lock™ joint: Easy two-step assembly by pushing the Supa Lock™ spigot end into the Supa Lock™ socket end, and clicking on the safety retainer, which is fitted on the spigot end of the valves and fittings. The safety retainer is easy to mount and demount, and as extra safety the patented Supa Lock™ joint prevents demounting when the system is under pressure. The joint is sealed by two large O-rings of drinking water approved EPDM rubber. The O-rings are placed on the spigot ends of the valves and fittings
  • The Supa Lock™ outlet is designed with rotation stop to prevent rotation during the tapping/drilling process
  • Ø32 bore for standard drill bit sizes
  • Main gasket towards pipe of EPDM
  • Maximum tightness with two thick O-rings sealing against the saddle head and the blade
  • Bolts of stainless steel A2 with antifriction coating, supported by large ears
  • POM cassette sealed with two O-rings of EPDM ensures tigthness from both sides
  • Cover of POM with an NBR gasket for permanent seal once tapping is complete

Downloads

Datasheets
Installation

Reference nos. and dimensions:

Scroll for more info
AVK ref. no. DN
mm
D
mm
L
mm
H
mm
H3
mm
W
mm
Theoretical
weight/kg
100-090-30-320464 80 90 121 150 210 159 4.5
100-110-30-320464 100 110 141 160 232 182 5.3
100-125-30-320464 125 125 160 170 254 207 7.0
100-140-30-320464 125 140 180 180 272 226 8.3
100-160-30-320464 150 160 171 185 285 237 7.9
100-200-30-320464 200 200 201 210 332 300 12
100-225-30-320464 200 225 201 220 358 322 13
2D/3D drawings
Enquiry
Scroll for more info

Components

1. Bolt Stainless steel A2
2. Washer Stainless steel A2
3. Saddle, upper part Ductile iron GJS-400-15 (GGG-40)
4. Cassette POM
5. O-ring EPDM rubber
6. Support ring POM
7. Gasket EPDM rubber
8. Liner SBR rubber
9. Liner SBR rubber
10. Saddle, lower part Ductile iron GJS-400-15 (GGG-40)
11. Cover POM
12. Cover gasket NBR rubber
13. Bolt Stainless steel A2
14. Washer Stainless steel A2
15. Nut Stainless steel A4
