AVK HANDWHEEL FOR FIRE PROTECTION VALVES

Fitting all standard gate valves, #14-27

Michael Nielsen, Product Manager, Fire protection and water supply

Contact

Michael Nielsen

Product Manager, fire protection & water supply

Handwheel assembled with bolt and washer

For manual operation of AVK gate valves. AVK recommends usage of our handwheels. AVK handwheels are of grey cast iron GJL-250 (GG-25) with epoxy coating to DIN 3476 part 1 and EN 14901.

fire
fire
Variant 08/A-011
Connection: Connection for stem square #14-27
Material: Cast iron
DN: DN40 - DN300

Features

  • Handwheel for gate valves with red epoxy

Downloads

Datasheet
Outline drawings

Reference nos. and dimensions:

Scroll for more info
AVK ref. no. DN/DN
D
mm
F
mm
Theoretical
weight/kg
08-050-01-200 40 - 50 180 14 1.5
08-100-01-200 100 - 100 280 19 3.5
08-150-02-200 125 - 150 320 19 4.5
08-200-01-200 200 - 200 320 24 6.0
08-250-02-200 250 - 300 500 27 11
Enquiry
Scroll for more info

Components

1. Handwheel Cast iron GJL-250 (GG-25)
2. Washer Stainless steel A2
3. Bolt Stainless steel A2
